LOGIC CARTRIDGE VALVE LC32DR40E7X/

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LC32DR40E7X/ (R900912563) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a set value. This hydraulically actuated valve features a spool valve with pilot operation and utilizes spool symbol B A for directional control. It is capable of handling a maximum pressure as defined by its product group ID, while the number of ports, size, and maximum flow rate are specified according to its particular model code. The LC32DR40E7X/ is equipped with a cartridge valve type of connection that adheres to the ISO connection diagram standards. This model is part of the way cartridge valves for pressure functions, specifically engineered as pilot-operated valves in seat or spool design. The power section, designed as a cartridge valve, fits into receiving holes standardized according to DIN ISO norms and is secured with a control cover. The pilot control valve can be either manually or electrically proportionally adjusted for pressure and is integrated into or mounted on the control cover in accordance with DIN specifications. The LC32DR40E7X/ offers various pressure functions by combining cartridge valves with control covers. Its pressure reducing function maintains an open rest position. Notably, this model does not exhibit an area difference at port B, meaning there are no effective areas at this port which influences the behavior of the spool under varying pressures. The effective pressure at port A is directed via an orifice to the spring side of the spool which remains open under set conditions allowing free flow from port B to A. Upon reaching the set pressure, the spool closes, reducing the pressure at port A according to its characteristics. The valve's seals are made from NBR material suitable for hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC.
