IH20M2A-VS10A01-1X/M01

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth IH20M2A-VS10A01-1X/M01 (R900773110) is a sophisticated modular control system designed for customization through various modules and additional vertical stackings. It is part of a versatile range that caters to different functionalities based on the selection of modules and valves, particularly suited for direct operated or internally pilot-operated directional valves. The product's adaptability is highlighted by its capability to accommodate other function modules across frame sizes A and B, with options for larger nominal volume flows in frame sizes C and D available upon request. This control system's maximum volume flows are determined by the permissible flow velocities within the application it serves, as well as the thread connections or connection flanges present at the IH modules. Its actuator ports are typically positioned on the back for accessibility and integration ease. The IH20M2A-VS10A01-1X/M01 assembly generally comprises an inlet segment, intermediate segments, sandwich plates, valves, way cartridge valves logic, accumulator segment, check function in P, valve segment, pump inlet segment, inlet segment right, and threaded bolt. Bosch Rexroth's design facilitates the construction of compact controls that are ready for connection. The system allows different sizes within one frame size to be combined in any sequence. Both pressure and tank ports are conveniently located on the front sides of mounted IH stacking assemblies for all control circuits. Each control circuit has separate actuator ports A and B. The material number provided includes the specific segment along with all necessary plug screws and seals; however functional elements such as valves or nozzles must be obtained separately. For complete circuit diagrams and device lists pertaining to a full IH stacking assembly setup, users should refer to the order documentation specific to this model code.
