***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WP6Y6X/N (R900761689) is a high-performance, direct operated directional spool valve designed for controlling the start, stop, and direction of fluid flow in hydraulic systems. This valve is part of the WP series and features pneumatic actuation, which allows for precise control over the hydraulic functions. The housing includes a control spool that can be shifted to desired positions using actuation elements such as a pneumatic actuation cylinder.
The 4WP6Y6X/N model comes with radial ports for control and one or two return springs that hold the control spool in a central or initial position when de-energized. For operations where flows exceed the valve’s performance limit during switching processes, a throttle insert can be used in channel P to mitigate this issue.
This particular model offers flexibility with its design options. It is available without spring return and with detent (version ..OF..), allowing each spool position to be locked. Alternatively, it can be ordered without spring return and without detent (version ..O..), meaning there will be no defined spool position when the valve is de-energized.
The 4WP6Y6X/N complies with porting patterns according to DIN form A without locating holes and ISO with locating holes. Subplates required for mounting this directional valve are available but must be ordered separately. Additionally, this unit can be equipped with inductive position switches and proximity sensors for contactless detection of the spool position.
With its robust construction and reliability, this Bosch Rexroth directional spool valve is suitable for various applications where precise fluid control is necessary. The maximum operating pressure stands at bar levels appropriate for its size category, while it ensures an optimal maximum flow rate measured in liters per minute (l/min).
$667.00 USD
More are expected on February 5, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 5, 2025 when ordered in
