4WRKE16W8-200L-3X/6EG24ETK31/F1D3M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRKE16W8-200L-3X/6EG24ETK31/F1D3M (R900715040) is a state-of-the-art pilot-operated, two-stage proportional directional valve designed with electrical position feedback and integrated electronics OBE. This product boasts exceptional control of flow direction and magnitude through its proportional solenoid operation. Ideal for subplate mounting, it adheres to the porting pattern specified by ISO standards. The main stage of this valve is position-controlled, ensuring the control spool position remains stable and unaffected by flow forces, even during high-flow scenarios. The unit features a spring-centered main control spool that, in the absence of an input signal, remains centrally positioned by a centering spring. It comes equipped with an inductive position transducer that communicates with suitable control electronics to facilitate precise valve operation. This model's pilot control valve is a single-stage proportional directional valve that effectively converts electric current into mechanical force without compromising on performance across its entire control stroke. The device's construction includes a durable housing and covers, a robust main control spool, centering springs, as well as an advanced pressure reducing valve. For optimal functioning, the tank lines should maintain fluid levels to avoid running empty; under certain installation conditions, installing a preload valve with approximately 5 bar preload pressure is recommended. The 4WRKE16W8-200L-3X/6EG24ETK31/F1D3M's modular design permits straightforward zero point adjustments within ±10% of the nominal stroke via an onboard potentiometer. Access to the integrated control electronics for fine-tuning is achieved by removing a plug screw on the front side of the cover housing. It's important to note that any adjustments should be carried out exclusively by trained professionals to prevent potential system damage.
