PROPORTIONAL DIRECTIONAL VALVE 4WRAE10W30-2X/G24K31/F1V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRAE10W30-2X/G24K31/F1V (R900711868) is a high-performance industrial hydraulic valve, designed to provide reliable control of oil flow direction in accordance with its hydraulic symbol W. This direct-actuated spool valve features integrated electronics for electrical actuation, ensuring precise operation and control. The valve is suitable for subplate mounting with a porting pattern conforming to ISO standards. The Bosch Rexroth 4WRAE10W30-2X/G24K31/F1V valve operates using two proportional solenoids which are controlled by the integrated electronics. These solenoids have a central thread and can be detached if necessary. The valve's operation is characterized by its spring-centered control spool, which returns to the central position when the solenoids are deenergized. The spool moves in proportion to an electrical input signal when one of the solenoids is energized, allowing for precise modulation of flow. This particular model is equipped with FKM seals and offers analog connectivity with a command value input range of 4-20 mA. It supports various types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, and HFDR. The valve has multiple ports and features a concealed manual override as well as an auxiliary actuation option. With its robust design and versatile capabilities, the Bosch Rexroth 4WRAE10W30-2X/G24K31/F1V valve excels in applications requiring precise control over fluid direction and flow rate without feedback on the spool position. Its electrical connection utilizes a connector pole PE according to EN standards and it operates at a supply voltage of 24 VDC. Users must ensure that the tank line does not run empty during operation; if necessary, installing a preload valve with a preload pressure of approximately 5 bar may be required for optimal functionality.
