DIRECTIONAL SPOOL VALVE 4WE6D6X/EG96N9K4/B10

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6D6X/EG96N9K4/B10 (R900707217) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction. This direct-actuated spool valve features a spool symbol D and is capable of handling a maximum pressure with an electrical connection description of a connector pole PE according to EN. It belongs to Productgroup ID and comes with four ports, solenoid actuation type, and conforms to CE standards, including the LowVoltage Directive EU and CSA approval according to CSA C. No. 22.2. With a size 6 CETOP pattern, this valve has an electrical connector with a connector pole PE and supports a maximum flow rate. The connection diagrams are compatible with NFPA T3.5.1 R2-2002 D03 and ISO 4401 patterns. It operates on a supply voltage of 24 VDC and offers two switching positions while weighing in at approximately .65 kg. The seals are made from NBR, suitable for hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. This Bosch Rexroth directional valve is available in either 3-way or 4-way versions with porting patterns according to ISO standard 4401-03-02-0-05 with or without locating holes. It features high-power solenoids that can be optionally rotated by 90° for flexible installation requirements. Electrical connections can be made via single or central connections with optional auxiliary operating devices available for manual control when needed. Additionally, spool position monitoring can be included as an option for enhanced control precision. For electrical safety compliance, the valve meets CE conformity for voltages greater than 50 VAC or 75 VDC and the solenoid coil comes with UR marking according to UL standard edition, which is optional along with the CSA approval. In summary, the Bosch Rexroth model code 4WE6D6X/EG96N9K4/B10 offers robust performance for controlling flow direction in hydraulic systems with its versatile design options catering to various application needs while ensuring compliance with international standards for safety and performance.
