LFA16EH2-7X/CA40DQMG24FV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LFA16EH2-7X/CA40DQMG24FV (R900706560) is a state-of-the-art way cartridge valve designed for seamless integration into compact block systems. This model features a modular setup, allowing for a variety of control covers to be implemented depending on the required functions, such as pressure, directional, and throttle controls or combinations thereof. The power section with connections A and B can be easily installed into a standardized receiving hole in the control block and secured with a cover that also serves as the connection point to pilot control valves. The LFA16EH2-7X/CA40DQMG24FV valve is efficient and cost-effective due to its capability to be adjusted for various flow rates corresponding to different actuator paths. It consists of several components including a control cover that houses the control bores and may feature stroke limitation, hydraulically controlled directional seat valves, or shuttle valves. Additionally, electrically operated directional spool or seat valves can be accommodated on the control cover. The installation kit comprises essential parts like a bushing, ring (up to NG), valve poppet (with optional damping nose), and closing spring. This model's functionality is pressure-dependent with three critical pressurized areas (A1, A2, A3) contributing to its operation. The valve allows for flow from A to B or vice versa with assured non-leakage blockage when area A3 is pressurized by pilot oil discharge from channel B or an external pilot oil supply. Furthermore, the LFA16EH2-7X/CA40DQMG24FV boasts an optimized design characterized by high flows, low pressure drops, high switching velocities, and minimal leakage oil flows. Its robust construction ensures high reliability and an extended lifecycle while maintaining a compact size and low weight for easy installation and maintenance. This way cartridge valve exemplifies Bosch Rexroth's commitment to producing versatile and durable hydraulic components suitable for various applications requiring precise fluid control.
