4WRSE6V04-3X/G24K0/A1M-280

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRSE6V04-3X/G24K0/A1M-280 (R900704205) is a high-response directional control valve equipped with integrated control electronics OBE, designed for direct operation in plate design. This precision-engineered valve features a robust housing with a connection surface, a control spool balanced by compression springs, and high-performance solenoids that enable precise control of the hydraulic flow. The position transducer within the system ensures accurate feedback, crucial for applications requiring exact positioning and velocity control. This valve operates by shifting the control spool proportionally to an electric input signal when the solenoids are energized. For example, energizing control solenoid b causes the spool to displace to the left, altering the connection from P to A and B to T through orifice-type cross-sections that provide linear flow characteristics. When deenergized, the compression spring returns the spool to its central position. Notably, in its default state without electrical power, mechanical springs hold the spool in a central position which may differ from the hydraulic central position; however, when activated electrically within a closed-loop system, it achieves precise hydraulic centering. The 4WRSE series valve is suitable for subplate mounting and adheres to porting patterns according to DIN form A and ISO standards. It showcases exceptional response sensitivity and low hysteresis due to its direct operation mechanism. The integrated OBE electronics facilitate streamlined setup and operation while ensuring reliability in performance. This Bosch Rexroth valve is ideal for applications where accurate flow direction and size control are essential for maintaining desired performance parameters in hydraulic systems.
