4WRSE6V10-3X/G24K0/A1M-644

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRSE6V10-3X/G24K0/A1M-644 (R900700504) is a high-response directional control valve designed for direct operation and plate mounting. This advanced hydraulic component is engineered to control the flow direction and size, making it suitable for precise position and velocity control applications. The valve features integrated control electronics OBE, which are responsible for controlling the solenoids that operate the valve. The setup of this unit includes a housing with a connection surface, a control spool balanced by compression springs, solenoids, and an integrated position transducer along with the OBE. Additionally, it offers zero point adjustment that can be accessed through a Pg cover. In terms of functionality, when the solenoids are de-energized, the central position of the control spool is maintained by compression springs. Upon energization of a solenoid (for example, control solenoid b), the control spool moves proportionally to the electric input signal allowing fluid to flow between ports P to A and B to T through orifice-type cross-sections with linear characteristics. This model boasts high response sensitivity and low hysteresis, essential for applications that demand quick and precise movements. The WRSE series valves are known for their direct operation with electrical position feedback that ensures accuracy in controlling hydraulic systems. For mounting purposes, this valve complies with porting patterns according to DIN form A and ISO standards. The Bosch Rexroth 4WRSE6V10-3X/G24K0/A1M-644 stands out as an efficient solution for users needing reliable directional control in advanced hydraulic systems where precision is critical. Its integrated electronics simplify installation and improve responsiveness, making it an ideal choice for sophisticated industrial applications requiring high-performance directional control valves.
