DBW10B2-5X/200S6EG96N9K4R12

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DBW10B2-5X/200S6EG96N9K4R12 (R900619411) is a sophisticated pilot-operated pressure relief valve designed for high-performance hydraulic systems. This valve serves the crucial function of limiting and solenoid-actuated unloading of operating pressure, ensuring system safety and efficiency. The DBW10B2-5X/200S6EG96N9K4R12 is composed of a main valve with a spool insert, a pilot control valve with an adjustable pressure element, and an integrated directional spool valve. One of the key features of this model is its ability to dampen switching shocks via its sandwich plate design, which delays the opening from port B to B. This helps in reducing pressure peaks and acoustic decompression shocks in the return line, providing smoother operation and enhanced longevity for hydraulic equipment. It achieves this by controlling the mounted directional spool valve. For versatile installation options, this model supports subplate mounting with porting patterns that comply with ISO standards NG6, NG10, and NG16. Additionally, it can be used as a screw-in cartridge valve for threaded connections. Users can select from various adjustment types for precise pressure settings, including a rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, or a rotary knob with scale. The DBW10B2-5X/200S6EG96N9K4R12 offers multiple pressure ratings and is capable of solenoid-operated unloading via built-on directional spool or poppet valves. Equipped with high-power solenoids for reliable actuation, it also provides optional switching shock damping to further refine system performance. The recommended nozzle size for ordering code R ensures optimal damping decompression shock according to specific application needs.
