3WEH10A7-4X/6EG24NTK4

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3WEH10A7-4X/6EG24NTK4 (R900617182) is a high-performance directional spool valve designed for controlling the start, stop, and direction of fluid flow in hydraulic systems. The valve features electrohydraulic actuation and is suitable for subplate mounting with porting patterns according to ISO standards. It can come in 3- or 4-way versions and offers options for spring or pressure centering, as well as spring end position or hydraulic end position. Built with a robust housing and equipped with wet-pin DC or AC solenoids, the valve ensures reliable operation under various conditions. The electrical connection can be configured as an individual or central connection depending on the application's requirements. The main control spool is maintained in the neutral position by return springs or pressurization, ensuring stability and precision in the control of hydraulic flow. For enhanced flexibility, this model includes optional features such as manual override for emergency operations, switching time adjustment for optimal control of system dynamics, preload valve in channel P of the main valve for maintaining system pressure, and stroke setting and/or spool position monitoring to ensure accurate positioning. The 3WEH10A7-4X/6EG24NTK4 valve also allows for internal or external pilot oil supply and return configurations. This flexibility ensures that it can be adapted to a wide range of hydraulic circuit designs. Additionally, its design accommodates throttle inserts when there's a need to limit pilot oil supply in channel P of the pilot control valve. This Bosch Rexroth directional spool valve is engineered to meet demanding performance criteria while offering customization through its various actuation types and optional components. It is an essential component for sophisticated hydraulic systems requiring precise flow direction control.
