SL6PB1-6X/V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SL6PB1-6X/V (R900594742) is an advanced isolator valve designed for subplate mounting, offering precise control in hydraulic systems. This releasable check valve is engineered to ensure leakage-free blocking of an actuator port even during extended periods of inactivity. It features a robust construction that includes a housing, seat poppet, compression spring, and control spool. An optional preopening feature as a ball seat valve enhances its functionality. The SL6PB1-6X/V operates by allowing free flow from direction A to B without the need for external pilot pressure, provided the condition pA > pB (cracking pressure of the compression spring) is met. Conversely, it seals hydraulically tight when flow is attempted in the opposite direction. The application of sufficient pilot pressure at port X displaces the control spool and lifts the seat poppet from its seat, enabling bidirectional flow and active keeping open. The valve’s performance can be tailored through various options, including versions with large spool face A connected to pA or without preopening (Version B). Version A with preopening benefits from a two-stage setup that allows secure unloading even at low pilot pressures while mitigating switching shocks through dampened decompression. In contrast, Version B may experience sudden unloading of pressure volume leading to potential switching shocks and noise. Furthermore, users can modify this type SV to type SL by exchanging plugs; one plug must always be installed to maintain functionality. This flexibility makes the SL6PB1-6X/V suitable for diverse hydraulic applications requiring reliable isolation capabilities. Additional features include compatibility with porting patterns according to ISO standards for easy integration into existing systems. The valve offers various cracking pressures and can be ordered with or without preopening based on system requirements. Check valve installation sets are available individually for maintenance or upgrades, and a corrosion-resistant design is optional for harsh environments. The maximum operating pressure stands at bar level while it can handle maximum flow rates measured in liters per minute (l/min), ensuring high-performance operation across a range of hydraulic tasks.
