DZ6DP1-5X/210XM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DZ6DP1-5X/210XM (R900581169) is a direct operated pressure sequence valve designed for the precise control of hydraulic systems. This model is engineered to facilitate the pressure-dependent connection of a secondary system by setting the sequencing pressure through an adjustable component. The valve features a compression spring that maintains the control spool in its initial position, ensuring the valve remains blocked until the desired pressure threshold is reached. Upon reaching the set value of the compression spring, the control spool shifts to enable a connection from channel P to A, allowing for an uninterrupted flow without any pressure drop in channel P. This model offers flexibility in receiving control signals either internally from channel P or externally via port BX. It also provides options for leakage oil discharge, which can be executed externally through port TY or internally via channel A. It's important to note that with internal leakage oil discharge, there will be an increase in set cracking pressure due to the influence of pressure within channel A. The DZ6DP1-5X/210XM allows for the integration of an optional check valve for free return flow of hydraulic fluid from channel A back to P, enhancing its versatility. For monitoring purposes, a pressure gauge connection is available for checking sequencing pressure directly at the valve. The DZ6DP1-5X/210XM adheres to DIN form A standards for subplate mounting without locating holes and ISO standards with locating holes; however, subplates must be ordered separately. This model boasts multiple adjustment types including rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, and rotary knob with scale. Additionally, users have options regarding maximum operating pressures and flow rates as well as component series designation and size specifications. With its robust design and adaptable features, this Bosch Rexroth sequence valve is well-suited for sophisticated hydraulic applications requiring reliable performance and precise pressure management.
