DB25G1-5X/200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DB25G1-5X/200 (R900539028) is a sophisticated pressure relief valve designed for subplate mounting and is crucial for regulating operating pressure in hydraulic systems. This pilot-operated valve includes a main valve with a spool insert and a pilot control valve featuring an adjustable pressure element. The device operates by channeling pressure to the main spool, which, in conjunction with the pilot control valve, manages the flow of hydraulic fluid to maintain set pressure levels. This model is equipped with various nozzles that create a pressure drop, triggering the connection between channels P and T to open when the operating pressure surpasses the preset value. The excess fluid is then directed back into the tank, ensuring consistent performance and preventing overpressure conditions. Additionally, this valve offers versatility through an unloading feature or by switching to an alternative second pressure rating via port X. Bosch Rexroth's DB25G1-5X/200 is compatible with multiple porting patterns according to ISO standards NG6, NG10, and NG16. It can also be utilized as a screw-in cartridge valve for threaded connections. Users have several adjustment options for setting the desired pressure levels, including a rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. With its corrosion-protected design and various pressure ratings available, this relief valve meets stringent performance criteria while ensuring durability in challenging environments.
