R900535030

DB10-2-5X/100/12

Manufacturer: Bosch Rexroth

Material #: R900535030

Model : DB10-2-5X/100/12


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DB10-2-5X/100/12 (R900535030) is a sophisticated pressure relief valve designed for controlling and limiting operating pressure within hydraulic systems. This pilot-operated valve is comprised of a main valve with a spool insert and a pilot control valve that includes a pressure adjustment element. The device operates by channeling hydraulic fluid through control lines equipped with nozzles, which, when the set pressure is exceeded, allows the ball in the pilot control valve to open against its spring. This action controls the flow of hydraulic fluid from channel P to T, thereby maintaining the desired operating pressure. The DB10-2-5X/100/12 valve offers versatility through its unloading feature and the ability to switch to an alternative second pressure rating via port X. It is designed for subplate mounting with porting patterns conforming to ISO standards NG6, NG10, and NG16. Additionally, it can be used as a screw-in cartridge valve for threaded connections. Users can select from various adjustment types for setting the pressure, including a rotary knob, sleeve with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. This model ensures durability and longevity even in harsh conditions thanks to its corrosion-protected design. It also provides flexibility in terms of size and component series X options. The maximum operating pressure capability stands at 350 bar while it can accommodate maximum flow rates up to 160 l/min depending on the size selected. The DB10 series valves are engineered for precision in maintaining system pressures and are suitable for various hydraulic applications where reliable pressure relief is critical.

$896.00 USD

More are expected on November 22, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as November 22, 2024 when ordered in

This product is eligible for factory repair.
