DR10DP2-4X/210YV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP2-4X/210YV (R900525725) is a high-performance direct operated pressure reducing valve designed for subplate mounting with a porting pattern according to DIN Form D and ISO standards. This valve is part of the component series X and is capable of handling maximum operating pressures up to 210 bar, with a maximum flow rate specified in liters per minute. The DR10DP2-4X/210YV valve is engineered to limit system pressure by setting the secondary pressure through an adjustable type, ensuring consistent performance. In its initial position, the valve permits unrestricted hydraulic fluid flow from channel B to channel A, while the pressure in channel A is controlled via a control line acting on a piston area against a compression spring. When the preset spring value is exceeded, the control spool activates to maintain a constant pressure level in channel A. The valve features internal signal and pilot oil supply from channel A and has external leakage oil discharge via channel TY. For scenarios where increased pressure in channel A occurs due to external forces on the actuator, the control spool counters this by connecting channel A to TY through the control edge, allowing excess fluid to discharge into the tank and preventing significant pressure increases. Optional features for this model include a check valve for free flow back from channel A to B and various adjustment types such as rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale. Additionally, it includes a pressure gauge connection for monitoring secondary pressure. The Bosch Rexroth DR10DP2-4X/210YV valve's design ensures reliable operation in various hydraulic applications where precise pressure reduction is required.
