PRESSURE RELIEF VALVE -Z ZDB10VA1-4X/200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDB10VA1-4X/200 (R900501258) is a high-performance pilot-operated pressure relief valve designed for sandwich plate mounting, providing efficient control for limiting system pressure. This valve is part of the ZDB series, known for its reliable operation in hydraulic systems. It features a robust housing that incorporates one or two pressure valve cartridges based on the application needs. The ZDB10VA1-4X/200 valve operates by maintaining the desired system pressure through an adjustable spring mechanism. In its default state, the valve remains closed, with the spool being influenced by the pressure in channel A and balanced by a spring force. Upon reaching a set pressure threshold, which can be adjusted via various adjustment types such as a rotary knob or a lockable rotary knob with scale, the pilot poppet is triggered to open. This action allows hydraulic fluid to flow from the spring-loaded side of the spool through designated nozzles into channel T TA, prompting the spool to shift and establish a connection from A to T TA, thus regulating the system pressure at pre-set levels. The ZDB10VA1-4X/200 valve's design offers flexibility with multiple adjustment types for precise pressure settings and features options for corrosion protection, ensuring longevity and reliability in challenging environments. It adheres to ISO standard porting patterns and accommodates different circuit options with its 200 bar rating. Whether equipped with one or two cartridges, this Bosch Rexroth valve stands as an essential component for hydraulic systems requiring accurate pressure relief functions.
