PRESSURE REDUCING VALVE DR10DP2-4X/75YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR10DP2-4X/75YM (R900500547) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a set value. This spool valve is directly actuated and features a P A spool symbol, indicating its function in controlling the flow from channel B to channel A. The valve operates under a maximum pressure, with the ability to manage max flow rates efficiently. This model, suitable for subplate mounting, adheres to the CETOP D size standards and connects according to ISO diagrams. It is equipped with NBR seals and is compatible with various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. The mechanical actuation of this valve allows for precise secondary pressure settings via an adjustment mechanism. In its default state, the DR10DP2-4X/75YM valve permits unrestricted flow from B to A while maintaining constant pressure levels in channel A through an internal control line that activates against a compression spring if exceeded set values. An external force that increases pressure in channel A will cause further displacement of the control spool against the spring tension, allowing excess fluid to discharge into the tank through channel TY. The design includes an external leakage oil discharge from the spring chamber through channel TY and has provisions for an optional check valve installation for free flow back from A to B. Additionally, it has a pressure gauge connection for monitoring secondary pressure. The DR10DP2-4X/75YM offers various adjustment types such as rotary knobs (standard or lockable with scale), threaded pins with hexagon and protective cap, ensuring versatility for different system requirements. Its robust construction ensures reliability in maintaining system pressures within safe operating parameters.
