THROTTLE CHECK VALVE Z2FS6-2-4X/2Q

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z2FS6-2-4X/2Q (R900481622) is a high-performance industrial hydraulic twin throttle check valve designed for precise flow regulation. This sandwich plate valve is engineered to reliably throttle the flow to a set value, offering direct actuation with a mechanically actuated setscrew featuring a lock nut. It is designed with spool symbols A A, B B or A A, B B, ensuring versatility for different hydraulic circuit configurations. The Z2FS6-2-4X/2Q valve operates with maximum efficiency under a high-pressure environment and is suitable for various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. The seals of this valve are made from NBR (nitrile butadiene rubber), which provides excellent resistance to oils and hydraulic fluids. This model features two throttle check valves that are aligned symmetrically to limit flows in one direction while allowing free return flow in the opposite direction. The throttling point can be finely adjusted via the setscrew to control the hydraulic fluid flow rate to the actuator. Moreover, it can be used for either main or pilot flow limitation applications by installing it between directional valves and subplates or between pilot control valves and main valves respectively. The Bosch Rexroth Z2FS6-2-4X/2Q valve boasts an NFPA T3.5.1 R1 D03 size CETOP 3 mounting pattern according to ISO standards with locating holes for easy installation. It comes with various adjustment types including a lockable rotary knob with scale and spindle with internal hexagon and scale options. Designed for durability and consistent performance, this model has a robust construction that ensures long service life even in demanding industrial environments. With its maximum operating pressure of bar and maximum flow rate of l/min, the Bosch Rexroth Z2FS6-2-4X/2Q valve stands as an essential component for any sophisticated hydraulic system requiring precise flow control.
