THROTTLE CHECK VALVE Z2FS6-5-4X/2QV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth Z2FS6-5-4X/2QV (R900476838) is a high-performance industrial hydraulic valve designed for reliable throttling of flow to a set value. This direct-actuated twin throttle check valve is mechanically actuated and comes in a sandwich plate design, compatible with various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, and HFDR. The Z2FS6-5-4X/2QV features a spindle with an internal hexagon and scale for precise adjustments. This model has the capacity for main or pilot flow limitation of one or two actuator ports and is equipped with two symmetrically aligned throttle check valves. These valves limit flows in one direction while allowing free return flow in the opposite direction. The adjustment of the throttle spool can be achieved via a setscrew to modify the throttling point as required. The Z2FS6-5-4X/2QV can be used for both supply throttling and discharge throttling. For main flow limitation (Version Q), it is typically installed between the directional valve and subplate; for pilot flow limitation (Version Q), it is installed between the pilot control valve and the main valve. The valve offers various adjustment types including setscrew with lock nut and protective cap, lockable rotary knob with scale, and rotary knob with scale. Designed to conform to DIN standards in porting pattern form A and ISO standards with locating hole, this Bosch Rexroth hydraulic valve supports maximum operating pressures up to bar level and allows maximum flows measured in liters per minute. Whether utilized for velocity adjustment or switching time adjustment in hydraulic systems, this model ensures efficient operation across numerous applications without compromising on control precision or reliability.
