R900474395

SL10GB2-4X/M

Manufacturer: Bosch Rexroth

Material #: R900474395

Model : SL10GB2-4X/M


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SL10GB2-4X/M (R900474395) is a high-quality isolator valve designed for subplate mounting or threaded connection, providing leak-free blocking of one actuator port, even during prolonged periods of inactivity. The valve features a robust housing, seat poppet, compression spring, and control spool, with an optional preopening as a ball seat valve. It allows for flow from A to B without external pilot pressure and closes hydraulically tight in the reverse direction when pA > pB due to the cracking pressure of the compression spring. Pilot pressure at port X activates the control spool, enabling free flow in both directions by disengaging the seat poppet. The valve's operational integrity relies on balanced pressure ratios and area ratios at the control spool or seat poppet. It comes in two versions: Version A with preopening facilitates controlled decompression to minimize switching shocks and wear on components; Version B lacks preopening and may result in sudden unloading of pressure volumes. The SL10GB2-4X/M can be modified from type SV to SL by swapping plugs, ensuring one plug remains installed. Additionally, version U integrates a built-on directional valve allowing direct control over the seat poppet against system pressure. This versatile isolator valve is suitable for various applications with its pilot oil return feature (without preopening), potential attachment for directional valves, and availability in different cracking pressures. Corrosion protection ensures durability while check valve installation sets are available separately. With porting patterns conforming to ISO standards NG6, NG10, and NG16 and options for subplate mounting or threaded connection, it offers maximum operating pressures up to 315 bar and maximum flow rates up to 120 l/min.

$990.00 USD

More are expected on April 21, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as April 21, 2025 when ordered in

This product is eligible for factory repair.
