PRESSURE REDUCING VALVE DR6DP1-5X/75YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP1-5X/75YM (R900466591) is a high-performance industrial hydraulic valve designed for reliable pressure reduction to a preset value. This mechanically actuated spool valve is direct-actuated, with a spool symbol indicating P to A flow. It operates with a maximum pressure and is part of the product group ID that specifies its technical classification. The valve features multiple ports and utilizes mechanical actuation. With a size that conforms to CETOP D standards, the DR6DP1-5X/75YM offers subplate mounting and connects according to the NFPA T3.5.1 R2 D03 standard as well as ISO 4401-03. It is designed for maximized flow efficiency and comes equipped with NBR seals suitable for various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC types. The valve operates by allowing free flow from channel P to A when in the initial position. The secondary pressure can be adjusted via an adjustment type mechanism. When the secondary circuit's pressure exceeds the set value, the control spool activates to maintain constant pressure in channel A. An external increase in pressure at the actuator will cause further displacement of the control spool against the compression spring, connecting channel A to TY and discharging excess fluid into the tank. Externally discharged leakage oil from the spring chamber ensures proper operation while an optional check valve allows for free backflow from A to P. Monitoring of secondary pressure is facilitated by a pressure gauge connection. The DR6DP1-5X/75YM valve offers various adjustment types including rotary knob options – both lockable and with scale – as well as threaded pin with hexagon and protective cap configurations. Its design also allows for optional installation of a check valve for added versatility in application use. This model's component series X guarantees compatibility up to its maximum operating pressure bar rating and supports an optimal maximum flow measured in liters per minute (l/min).
