DR6DP2-5X/210YMV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP2-5X/210YMV (R900435680) is a high-performance direct operated pressure reducing valve designed for subplate mounting, with a way version that ensures the limitation of the secondary circuit's system pressure. This valve is adept at maintaining a consistent secondary pressure which is set through an adjustment type mechanism. In its initial position, the valve allows unrestricted flow from channel P to A, while simultaneously applying pressure through the control line to balance against the compression spring. When the pressure in channel A surpasses the set value on the compression spring, the control spool shifts to maintain a steady level. Internal signaling and pilot oil are routed via this control line from channel A. An increase in channel A's pressure due to external forces causes further movement of the control spool against the spring, connecting channel A to TY and allowing excess hydraulic fluid to flow back into the tank, thus regulating pressure effectively. The design ensures leakage oil from the spring chamber is discharged externally through channel TY. An optional check valve can be integrated for free flow back from channel A to P, enhancing versatility. Monitoring and maintenance are made convenient with a pressure gauge connection for secondary pressure checks. The model conforms with DIN form A and ISO porting patterns, including an optional locating hole for precise installation. It offers various adjustment types like rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, or rotary knob with scale for user-friendly operation. The unit supports different pressure ratings and includes an optional check valve for added functionality. With a maximum operating pressure of 210 bar and maximum flow rate specifications available upon order placement, this Bosch Rexroth valve meets stringent requirements for reliable hydraulic system performance across diverse applications.
