PRESSURE RED.VALVE INTERMEDIATE PLATE ZDR10DB2-5X/25YM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDR10DB2-5X/25YM (R900426202) is a high-performance, direct-operated pressure reducing valve designed for industrial hydraulic applications. This sandwich plate valve is engineered to reliably control and reduce system pressure to a predetermined setting. It features a spool valve that is mechanically actuated, with pressure adjustment capabilities ranging from bar. The ZDR10DB2-5X/25YM is constructed with a hexagon sleeve and protective cap for durability and ease of maintenance. This model has multiple ports and allows for maximum flow, adhering to the NFPA T3.5.1 R2 D03 size and CETOP D03 standards, with connection diagrams available in both NFPA and ISO formats. It includes a number of switching positions and weighs . kg, ensuring robust performance in various configurations. The valve utilizes NBR seals and is compatible with several types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. The ZDR10DB2-5X/25YM offers different versions (A, P, B) to cater to specific circuit requirements; each version provides internal control signal and pilot oil supply from designated channels (A or P). A unique feature of this model is the optional check valve in version A for free flow return from channel A to A. Additionally, the external leakage oil drain from the spring chamber ensures efficient operation. For accurate monitoring of secondary pressure levels, the valve includes a pressure gauge connection point. In scenarios without a directional valve or when setting up a directional seat valve NG6, appropriate sandwich plates must be used as specified by Bosch Rexroth guidelines. Overall, the Bosch Rexroth ZDR10DB2-5X/25YM stands out for its versatility in pressure reduction applications across various channels (A or P), its array of optional adjustment types including rotary knobs (with or without scale), lockable versions with scale, and its compatibility with different hydraulic systems through standardized porting patterns.
