DR6DP2-5X/25Y/12

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth DR6DP2-5X/25Y/12 (R900424293) is a high-performance direct operated pressure reducing valve designed for subplate mounting with a porting pattern according to DIN form A and ISO with an optional locating hole. This model ensures precise pressure limitation in the secondary circuit by utilizing an adjustment type that allows users to set the secondary pressure accurately. The valve's initial open position permits unrestricted flow from channel P to channel A, while the control line applies pressure to the piston area opposite the compression spring, maintaining a constant level of set pressure in channel A. The innovative design of this valve enables internal signal and pilot oil routing via the control line from channel A. An increase in pressure due to external forces on the actuator will move the control spool against the compression spring, connecting channel A to channel TY via the control edge on the spool. This action allows excess hydraulic fluid to discharge into the tank, preventing undue pressure build-up. Additionally, this model features external leakage oil discharge through channel TY from its spring chamber. An optional check valve can be installed for free flow back from channel A to P, enhancing versatility for various applications. Monitoring and maintenance are made more accessible by a pressure gauge connection for secondary pressure checks. The Bosch Rexroth DR6DP2-5X/25Y/12 comes with various adjustment types such as rotary knob, threaded pin with hexagon and protective cap, lockable rotary knob with scale, and rotary knob with scale. It also offers different pressure ratings and an optional check valve feature. With its size and component series X specifications, this model can handle a maximum operating pressure of up to 315 bar and a maximum flow rate of 25 l/min, making it suitable for demanding hydraulic applications requiring precise pressure control.
