PRESSURE RED.VALVE INTERMEDIATE PLATE ZDR10DA2-5X/210Y

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth ZDR10DA2-5X/210Y (R900406651) is a mechanically actuated industrial hydraulic valve designed for high-performance applications. This direct-operated spool valve features a reliable pressure reduction to its setting value, with an adjustment range specified in bars. The valve is equipped with a sleeve that has a hexagon and protective cap, making it robust for industrial environments. The ZDR10DA2-5X/210Y operates as a pressure reducing valve in sandwich plate design, ensuring pressure limitation of the secondary circuit to maintain system efficiency. It is comprised of several key components: housing, control spool, compression spring, and an optional check valve. The secondary pressure can be precisely set via the adjustment type provided on the valve. This model offers versatility with various versions such as A, P, and B to cater to different application requirements. Version A allows for free flow back from channel A to A through an optional check valve. The control signal and pilot oil are supplied internally from channel A in this version. For versions P and B, the pressure reduction occurs in channel P but differs in pilot oil extraction; version B extracts from channel B. It's crucial that if used without a directional valve, channels TA and TB should be connected appropriately. The ZDR10DA2-5X/210Y showcases multiple connection options including sandwich plate connections compatible with NFPA T3.5.1 R2 D03 size and CETOP R35H-4 size standards. It also adheres to ISO connection diagram standards for ease of integration into various hydraulic systems. This model is designed for a maximum operating pressure of bar and can handle maximum flow rates of l/min as specified by its performance range. It supports numerous hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC types with NBR seals ensuring durability against fluid corrosion and wear. In summary, the Bosch Rexroth ZDR10DA2-5X/210Y (R900406651) stands out as a robust solution for precise pressure regulation in demanding industrial hydraulic systems with its direct operation mechanism and customizable features tailored to specific application needs.
