H-4WMM16E7X/QMAG24/V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth H-4WMM16E7X/QMAG24/V (R900249823) is a high-quality directional spool valve designed for manual operation. This valve is part of the WMM series, known for its robust construction and precise control of fluid flow in hydraulic systems. The valve features a housing, hand lever, control spool, and one or two return springs that work together to initiate or cease fluid flow and manage the direction of that flow. The hand lever directly actuates the control spool, allowing for quick and easy changes from one position to another. When the hand lever is released, the return spring ensures the spool returns to its original rest position. The R900249823 model comes with a detent mechanism that securely locks the spool in any selected position, providing stability during operation. This particular model adheres to porting patterns according to DIN form A and ISO standards, ensuring compatibility with a wide range of systems. It boasts an actuation mechanism protected against contamination and moisture ingress, enhancing durability and reducing maintenance requirements. Additionally, users have the convenience of exchanging the head end with the actuation mechanism without needing to disassemble the entire valve—this feature simplifies maintenance and customization processes. Furthermore, this Bosch Rexroth valve can be equipped with optional inductive position switches and proximity sensors for contactless detection of spool position. These features enable integration into more complex control systems where feedback on valve position is essential for operational precision. The H-4WMM16E7X/QMAG24/V offers reliability and flexibility for various hydraulic applications where manual control over fluid directionality is required.
