BALL RUNNER BLOCK CARBON STEEL KWE-045-FLS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWE-045-FLS-C1-N-1 (R205B41420) is a high precision linear motion component designed for applications requiring robustness and rigidity. This BSCL ball runner block is of size 45, in the FLS format (flanged, long, standard height), and is constructed from unalloyed steel CS. It offers a low preload class C and standard accuracy class N, ensuring smooth motion without a ball chain. The runner block body comes with initial lubrication and preservation for immediate use. This product has an overall length of the runner block at 100 mm, and it can be mounted both from above and below due to its versatile design. The runner block boasts very high load capacities making it suitable for applications with significant rigidity requirements. With its ability to operate within a permissible ambient temperature range of -10°C to +100°C, it is adaptable to various working environments. The B.RUNNER BLOCK CS KWE-045-FLS-C1-N-1 features interchangeability as the runner block and guide rails can be combined with each other across all accuracy levels. Its static load rating C0 and dynamic load capacity C indicate that this component can handle substantial loads while maintaining performance. The static torsional moment load capacity Mt further underscores its stability in operation. This model does not include a seal which results in a lower friction coefficient between 0.01 to 0.02 without seal friction, contributing to efficient movement within systems. It also comes standard with initial lubrication and preservation for maintenance ease. Ideal for size B profiled rail systems, this Bosch Rexroth linear motion component ensures precise guidance with high dynamic capabilities including maximum permissible linear speed vmax and maximum acceleration amax parameters that cater to demanding motion tasks in various applications.
