R205B21420

BALL RUNNER BLOCK CARBON STEEL KWE-025-FLS-C1-N-1

Manufacturer: Bosch Rexroth

Material #: R205B21420

Model : B.RUNNER BLOCK CS KWE-025-FLS-C1-N-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWE-025-FLS-C1-N-1 (R205B21420) is a high-precision BSCL ball runner block designed for applications requiring high rigidity and load capacity. This runner block, with an overall length of . mm, features a flanged, long, standard height format (FLS) and is constructed from unalloyed steel CS. It is classified under preload class C, indicating a low preload, and accuracy class N for standard accuracy. The product does not include a ball chain but comes with initial lubrication and preservation for immediate use. The body of the runner block adheres to the standard version specifications. It offers interchangeability with guide rails of every accuracy level, ensuring flexibility in combination with other components. With its robust design, this runner block can be mounted from both above and below surfaces. It has a static load rating C that supports very high loads and exhibits a friction coefficient ranging between , without seal friction. The permissible ambient temperature for operation spans from C to C. This model is part of the size B profiled rail systems and can also integrate with size H, K, N, T, S profiled rail systems as well as those with specific tolerances. It showcases impressive static and dynamic torsional moment load capacities (Mt), along with dynamic load capacity (C) and longitudinal moment load capacity (ML). For motion performance, it supports maximum acceleration (amax) parameters and maintains operation within the specified friction coefficient range. The unit also includes standard seals (SS) to protect against contaminants. The B.RUNNER BLOCK CS KWE-025-FLS-C1-N-1 is suitable for various industrial applications where precision linear movement is essential. Its robust construction ensures durability while maintaining precise movement control in demanding environments.

$251.40 USD

More are expected on December 16, 2024
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as December 16, 2024 when ordered in
