BALL GUIDE RAIL CARBON STEEL KSE-025-SNS-N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R205520451) is a high-precision, carbon steel guide rail designed for robust linear motion applications. This BSCL ball guide rail is notable for its slimline width and standard height, conforming to the SNS format which offers a balanced profile for various installation requirements. The guide rail is furnished with plastic caps as coverings (Cover AK) and allows for convenient bolting from above (Fastener MA), ensuring easy assembly and maintenance. This model adheres to a standard accuracy class, making it suitable for a wide range of industrial applications where precise motion is essential but ultra-high precision is not critical. The factory length of these rails comes in four-meter sections without end machining, providing flexibility in usage and the possibility to customize based on specific application needs. The dynamic load capacity of this guide rail system is based on a travel life of 100,000 meters, indicating its durability and reliability over extensive use. It boasts a weight of 2.9 kg/m, which reflects its sturdy construction while maintaining an efficient mass-to-performance ratio. The recommended rail length formula provided ensures optimal performance when configuring the system to accommodate various loads. In terms of dynamic load ratings and torsional moment load capacities, the B.GUIDE RAIL CS demonstrates robust performance metrics that are crucial for applications demanding consistent and reliable linear movement under varying operational conditions. Its design caters to both T-profiled and N-profiled rail systems, with specific size recommendations ensuring compatibility and optimal functionality across different system configurations. Overall, the Bosch Rexroth B.GUIDE RAIL CS represents a versatile linear motion component that combines durability, precision, and ease of installation—a testament to Bosch Rexroth's commitment to engineering excellence in automation technology.
