R201132390

BALL RUNNER BLOCK HIGH-SPEED CARB. STEEL KWD-035-SNS-C2-H-1

Manufacturer: Bosch Rexroth

Material #: R201132390

Model : B.RUNNER BLOCK HS KWD-035-SNS-C2-H-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK HS KWD-035-SNS-C2-H-1 (R201132390) is a high-speed ball runner block designed for precision and speed in linear motion applications. This runner block features a slimline width, normal length, and standard height, fitting the SNS format. It is constructed from carbon steel CS for durability and has a medium preload (class C) with high accuracy (class H), ensuring reliable performance under various loading conditions. The B.RUNNER BLOCK HS is notable for its capability to handle very high travel speeds while maintaining maximum system rigidity due to its preloaded O-arrangement. It is equipped with ceramic balls that not only allow for electrical insulation but also contribute to the runner block's high-speed capabilities due to their low weight. The design facilitates long-term lubrication over several years, with an integrated reservoir for oil lubrication ensuring minimal maintenance. With dimensions tailored to integrate seamlessly into a variety of applications, the runner block has an overall length of . mm and can be used on all SNS/SNO ball guide rails. It boasts high load ratings in all four main directions of loading and features lube fittings with metal threads on all sides for easy maintenance. The absence of a ball chain standardizes this model while still providing smooth and quiet operation thanks to its optimized ball return and guideway design. This product comes prelubricated from the factory, eliminating initial maintenance requirements and ensuring immediate operational readiness upon installation. It's available in eight common sizes that cater to diverse application needs, offering flexibility in design integration. Additionally, the B.RUNNER BLOCK HS can withstand a wide range of operating temperatures from min ... max °C, making it suitable for various environmental conditions. Its dynamic load capacity C and dynamic torsional moment load capacity Mt are determined as per DIN ISO standards, providing users with reliable specifications for their engineering calculations.

$1,094.05 USD

Availability:  4  In Stock
  Add to Cart
Available for immediate shipment

Qty: Delivered as early as November 29, 2024 when ordered in
