BALL RUNNER BLOCK NRFG KWD-015-FNS-C0-H-0
Manufacturer: Bosch Rexroth
Material #: R200119314
Model : B.RUN. BLOCK NRFG KWD-015-FNS-C0-H-0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUN. BLOCK NRFG KWD-015-FNS-C0-H-0 (R200119314) is a high-precision ball runner block designed for demanding applications that require smooth, quiet motion and high rigidity. This model is part of the Resist NR series, which is particularly suited for the packaging industry and food industry subsectors due to its corrosion-resistant steel construction as per DIN standards. The runner block features a size 15 flange width, normal length, and standard height, ensuring it fits seamlessly into a variety of linear motion systems.
With an accuracy class H for high precision and preload class C indicating that it is preload-free, this ball runner block delivers reliable performance without initial lubrication or preservation. It does not include a ball chain or attachment elements on either reference edge, providing flexibility in integration with existing systems. The straight lube connection that comes loosely attached allows for easy maintenance and long-term lubrication over several years.
The overall length of the Bosch Rexroth R200119314 runner block is meticulously designed to ensure interchangeability across all SNS ball guide rails within each accuracy class. This feature enables limitless combination possibilities with guide rails, enhancing design flexibility. The product offers excellent dynamic characteristics with the same high load ratings in all four main directions of loading.
Additional design benefits include integrated all-around sealing to protect against contaminants, optimized entry-zone geometry for reduced variation in elastic deflection during operation, and improved rigidity under various loading conditions due to strategically placed mounting screw holes at the center of the block. Attachments can be mounted from both above and below the ball runner block, further increasing its adaptability in different installation scenarios.
$356.46 USD
More are expected on February 17, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 17, 2025 when ordered in
