BALL RUNNER BLOCK RESIST NR KWD-015-FKS-C0-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK NR KWD-015-FKS-C0-H-1 (R200019330) is a high-precision ball runner block designed for linear motion applications where corrosion resistance and accuracy are paramount. This particular model is part of the FKS series, which features a flange width, short length, and standard height configuration. The runner block body is constructed from DIN EN corrosion-resistant steel, ensuring durability and longevity even in harsh environments. With an accuracy class of H, this runner block offers highly accurate motion control. It is preload-free (preload class C), meaning there's no initial tension in the bearing system, which can be advantageous in certain applications where reduced friction and smooth movement are required. The absence of a ball chain contributes to its streamlined design. The B.RUNNER BLOCK NR KWD-015-FKS-C0-H-1 has been pre-lubricated with Roller bearing grease Dynalub 510 for initial operation and comes with preservation for added protection. It boasts an overall length of the runner block at 63 mm and can handle maximum permissible linear speeds efficiently. Interchangeability is a key feature of this model; it can be combined with guide rails of every accuracy level to meet various application requirements. Its patented entry zone increases travel accuracy by up to six times compared to standard systems. The design allows attachments to be mounted from both above and below the runner block, offering flexibility in assembly. This model is suitable for applications with restricted space in the longitudinal direction and excels at reducing frictional oscillations while maintaining low friction force levels under external load conditions. Its excellent dynamic characteristics make it ideal for high-speed operations while ensuring maximum precision throughout its service life. Designed for long-term lubrication over several years, the B.RUNNER BLOCK NR KWD-015-FKS-C0-H-1 maintains its performance even under extreme temperature conditions ranging from -10°C up to 100°C for short periods of time. With dynamic load capacity C based on a 100 km travel as per DIN ISO standards and capability to withstand high load ratings in all four main loading directions, this product represents Bosch Rexroth's commitment to quality and performance in linear motion technology.
