LAUFROLLENWAGEN SUPER ALUMINIUM LWA-020-SKS-FN-E-0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LR-WAGEN SUPER AL LWA-020-SKS-FN-E-0 (R190611900) is a high-performance cam roller runner block designed for handling and automation technology applications. This super version runner block boasts a slimline SKS format with a short length and standard height, providing an economic accuracy class E. Its body is constructed from aluminum, ensuring a lightweight yet durable design suitable for standard load applications. The LR-WAGEN SUPER AL features a two-row angular contact ball bearing that is sealed and lubricated for life, offering high load capacity in all four main directions of loading, including moments about all axes. The runner block can be adjusted to zero clearance using eccentric spigots to ensure precise movement. It comes equipped with wiper and lubrication units on both sides that have a large oil reservoir, enhancing the maintenance intervals. Lube nipples are also included, allowing for easy lubrication access on both sides. This model is self-aligning to compensate for non-level mounting surfaces and other alignment errors, though it does not include self-alignment capabilities. It operates effectively within a temperature range of -10°C to +100°C and can handle maximum static loads due to resulting force in the y-direction (Fy max), as well as dynamic and static load capacities in the z-direction (Cz). The LR-WAGEN SUPER AL also supports significant dynamic loads in the y-direction (Cy), with maximum permissible linear speeds (vmax) specified for average loads. The unit's dimensions include an overall length of the runner block, height of the runner block with guide rail, width, and length specifications that fit within the size SW profiled rail systems. The weight is kept minimal without compromising on strength or performance. In summary, the Bosch Rexroth LR-WAGEN SUPER AL LWA-020-SKS-FN-E-0 (R190611900) is an efficient and reliable solution for linear motion requirements in various automation tasks, providing flexibility, precision adjustment capabilities, and long-term durability with minimal maintenance needs.
