R186123110

ROLLER RUNNER BLOCK CARBON STEEL RWA-100-FNS-C3-S-2

Manufacturer: Bosch Rexroth

Material #: R186123110

Model : R.RUNNER BLOCK CS RWA-100-FNS-C3-S-2


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWA-100-FNS-C3-S-2 (R186123110) is a high-precision roller runner block designed for linear guidance in heavy-duty machine construction applications that demand a very high carrying capacity and rigidity. This robust component is made of unalloyed steel CS and comes in size 100 with a flanged width, normal length, and standard height. It offers super precision accuracy (SP) and features a high preload class (C), ensuring minimal elastic deflection under load. The runner block's body is of the standard version, without an attached roller chain, initial lubrication, or attachment elements on either front reference edge. It includes straight lube connections loosely attached for ease of maintenance. With an overall length specified by the manufacturer, this runner block is interchangeable with guide rails of every accuracy level. The design includes three additional mounting screw holes at the center for improved rigidity under liftoff and side loading conditions. This product boasts impressive load capacities due to its optimized entry-zone geometry and the high number of rollers used. The innovative channel design allows for minimal lubrication quantities while ensuring smooth and quiet operation through optimally designed return channels and guideways. The integrated front seals enhance sealing effectiveness across all running tracks while also protecting plastic parts within the assembly. Furthermore, the Bosch Rexroth R.RUNNER BLOCK CS RWA-100-FNS-C3-S-2 is characterized by its ability to handle high torque loads efficiently. It provides limitless interchangeability and numerous combination options thanks to uniform Roller Guide Rails across all variants. Attachments can be mounted from both above and below the runner block, adding to its versatility in application. The dynamic load capacity C, static longitudinal moment load capacity ML, dynamic torsional moment load capacity Mt, friction force, permissible ambient temperature range, maximum permissible linear speed vmax, maximum acceleration amax, weight, nominal size are determined based on extensive testing as per DIN ISO standards for reliability in performance.

$9,593.85 USD

More are expected on March 21, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as March 21, 2025 when ordered in
