ROLLER RUNNER BLOCK CARBON STEEL RWD-055-FLS-C3-U-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-055-FLS-C3-U-2 (R18535392X) is a high-precision roller runner block designed for ultra-precise linear motion applications. This runner block features a size 55 flange format with an overall length of 126 mm and is made from unalloyed steel CS, ensuring durability and rigidity. It boasts a high preload class C, indicating a high degree of stiffness which is critical for maintaining accuracy under load. The accuracy class UP (Ultra Precision) further underscores its capability to perform in applications requiring the highest level of precision. This specific model does not include a roller chain, initial lubrication, or attachment elements on the left or right front reference edges. It does, however, come preserved and with a straight lube connection loosely attached for ease of maintenance. The runner block body is in the standard version and designed to be interchangeable with guide rails of every accuracy, allowing for flexibility in various system configurations. The RWD-055-FLS-C3-U-2 runner block excels in all four main directions of loading due to its high torque load capacity and maximum rigidity achieved through additional screw connections. Its innovative design ensures smooth and quiet operation while minimizing lubrication requirements. The optimized return and guideways contribute to the precision travel accuracy by providing smooth running conditions for the rollers. Maintenance is made easy with lube nipples possible on all sides, while attachments can be mounted from both above and below the runner block. Integrated all-around sealing comes as standard, protecting against contaminants and extending product life. This model offers uncompromised performance with minimal elastic deflection due to its advanced entry zone geometry and high roller count per track. Overall, the Bosch Rexroth R.RUNNER BLOCK CS RWD-055-FLS-C3-U-2 (R18535392X) represents an advanced solution for linear motion systems demanding utmost precision and reliability across various industrial applications.
