ROLLER RUNNER BLOCK CARBON STEEL RWD-065-FNS-C3-U-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-065-FNS-C3-U-2 (R18516392X) is a high-precision roller runner block designed for use in linear guidance systems requiring ultra precision and high preload. This model features a flanged width, normal length, and standard height with an overall length of . mm. It is constructed from unalloyed steel CS and boasts an accuracy class UP for ultra precision applications. The runner block body comes in a standard version without a roller chain, preserved but without initial lubrication, and lacks attachment elements on both left and right front reference edges. The straight lube connection is provided loosely attached for convenience. The runner block has been engineered to offer high torque load capacity with the same high load ratings in all four main directions of loading, ensuring maximum rigidity due to additional screw connections on two bore holes at the center. Its design allows for unrestricted interchangeability with all guide rail versions combinable with various roller runner block variants. The innovative channel design ensures minimum lubrication quantities are required while still providing smooth and quiet running due to the optimally designed return and guideways of the rollers. Attachments can be mounted on both top and bottom surfaces of the roller runner block, allowing for versatile use in different configurations. The integrated all-around sealing comes as standard, providing protection against contaminants. This model also features low elastic deflection and high precision thanks to its multi-optimized entry zone geometry and a significant number of rollers. The Bosch Rexroth R.RUNNER BLOCK CS RWD-065-FNS-C3-U-2 is designed to be easily slid onto the rail with a transport lock, making installation straightforward. It offers dynamic load capacities based on DIN ISO standards, indicating its suitability for demanding applications where precision and reliability are paramount.
