ROLLER RUNNER BLOCK CARBON STEEL RWD-045-SLH-C2-S-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-045-SLH-C2-S-2 (R18244212X) is a high-precision roller runner block designed for linear motion applications requiring super precision and medium preload. This product is part of the RSHP series, suitable for a wide range of typical applications as well as special installation, environmental, and operating conditions. The runner block body is constructed from unalloyed steel CS and features a slimline width, long length, and high height format (SLH). It boasts an accuracy class SP for super precision and comes without a roller chain, initial lubrication, or attachment elements on the left or right front reference edges. The RWD-045-SLH-C2-S-2 maintains high torque load capacity in all four main directions of loading and offers maximum rigidity due to additional screw connections on two bore holes in the center. It ensures smooth operation with its innovative channel design which also requires minimum lubrication quantities. The optimized return and guideways of the rollers contribute to quiet running. With an overall length of . mm, this roller runner block features integrated all-around sealing as standard and allows attachments to be mounted from both above and below. The multioptimized entry zone geometry alongside a high number of rollers ensures low elastic deflection and utmost precision during operation. This model can be used with different sizes and preload classes of profiled rail systems including size S with M thread diameter and size T with rail separation T. Furthermore, the R.RUNNER BLOCK CS RWD-045-SLH-C2-S-2 has interchangeable guide rails that can be combined with every accuracy level for enhanced versatility. Its dynamic load capacity C, static longitudinal moment load capacity ML, dynamic torsional moment load capacity Mt are determined based on a 100,000 m travel as per DIN ISO standards. With its robust design and precise engineering, this product offers reliable performance in various linear motion systems without requiring special designs for unique conditions.
