ROLLER RUNNER BLOCK CARBON STEEL RWD-045-SNH-C2-S-2-AS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.RUNNER BLOCK CS RWD-045-SNH-C2-S-2-AS (R18214212A) is a high-precision roller runner block designed for super precision applications with a medium preload. It features an SNH size, which denotes a slimline width, normal length, and high height profile. The runner block body is constructed from carbon steel CS, ensuring robustness and durability. This model is part of the RSHP series, which means it can handle typical applications as well as special installation, environmental, and operating conditions without the need for special designs. This roller runner block boasts a preload class C and an accuracy class SP, indicating its suitability for applications that require precise motion control and rigidity. It has been designed without a roller chain and comes with preservation but no initial lubrication. The absence of attachment elements on both left and right reference edges allows for flexible installation options. The RWD-045-SNH-C2-S-2-AS model provides maximum rigidity due to additional screw connections in the center bore holes and offers high torque load capacity in all four main loading directions. Its interchangeable design allows it to be combined with various guide rails within the same accuracy class. The innovative channel design ensures minimal lubrication requirements while lube nipples on all sides facilitate easy maintenance. This roller runner block operates smoothly thanks to its optimized return system and guideways of the rollers. Attachments can be mounted from both above and below the block for convenience. The integrated all-around sealing comes standard with this model, providing protection against contaminants. Designed to simply slide onto the rail with a transport lock, this Bosch Rexroth roller runner block offers low elastic deflection coupled with high precision due to its entry-zone geometry and numerous rollers. It adheres to DIN ISO standards for dynamic load capacities and load moments, ensuring reliable performance in demanding environments.
