CLAMPING ELEMENT KWH 6505 BS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT KWH 6505 BS1A (R181064211) is a hydraulic clamping unit designed for high precision and reliability in securing components on SNS roller guide rails. This robust unit features a solid, rigid steel housing that is chemically nickel-plated to ensure durability and resistance to harsh conditions. Its compact design is compatible with DIN standards, making it versatile for various applications. The KWH 6505 BS1A offers dynamic and static stabilization in the axial direction and boasts a high positioning accuracy. It is equipped with an integrated all-around sealing system and utilizes special pressure diaphragm technology to maintain functional reliability without pressure losses or leakage. The clamping element can securely hold components with its positivelocking, large-surface contact profiles that provide maximum axial rigidity. With the capability of enduring up to 1 million clamping cycles, this unit demonstrates exceptional longevity. It operates within a continuously adjustable pressure range from 0 to 450 bar, allowing users to customize the holding force as required for different tasks. Additionally, the clamping element has been tested to maintain performance across a temperature range from -20°C up to +80°C. Designed for ease of use, this model features threaded connections on both sides for hydraulic integration and supports decompression with spring force for swift release cycles. The KWH 6505 BS1A is suitable for various sizes of profiled rail systems including sizes A, B, E, H, N, and S. Its nominal size accommodates multiple applications while maintaining a weight of just 2.4 kg. Overall, the Bosch Rexroth CLAMPING ELEMENT KWH 6505 BS1A offers users a reliable solution for securing components with precision and strength in demanding industrial environments where stability and repeatability are paramount.
