CLAMPING ELEMENT KWH 5505 BS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT KWH 5505 BS1A (R181054211) is a premium hydraulic clamping unit designed to deliver dynamic and static stabilization in the axial direction. This unit is engineered for use with all SNS roller guide rails, showcasing its versatility across various profiled rail systems such as sizes A, B, E, H, N, and S. The KWH 5505 BS1A features a solid and rigid steel housing that is chemically nickel-plated to ensure durability and resistance to harsh conditions. The clamping element boasts a compact design that is compatible with DIN standards while providing high positioning accuracy. It operates with a hydraulic pressure range continuously adjustable from 0 bar upwards, ensuring precise control over the clamping force applied. The integrated all-around sealing coupled with special pressure diaphragm technology guarantees maximum functional reliability, preventing pressure losses or leakage during operation. This model offers exceptional axial rigidity thanks to its integrated positive-locking, large-surface contact profiles. It has been tested for up to 10 million clamping cycles, indicating its capability for long-term use without compromising performance. The product also features threaded connections on both sides for the hydraulic connection, adding to its ease of installation and maintenance. In terms of technical specifications, the KWH 5505 BS1A can withstand ambient temperatures ranging from -20°C to +80°C. Its nominal size fits various rail systems with specific dimensions for height and width of runner blocks detailed in the technical data provided by Bosch Rexroth. The functional principle involves direct pressing of large-scale clamping profiles through hydraulic oil via a piston principle onto the flanks of the Roller Guide Rail. Decompression is efficiently managed by a pretensioned return spring which allows for short cycles. Overall, the Bosch Rexroth CLAMPING ELEMENT KWH 5505 BS1A (R181054211) stands as an advanced solution for applications requiring reliable and precise clamping capabilities within linear motion technologies.
