CLAMPING ELEMENT KWH 4505 BS1A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT KWH 4505 BS1A (R181044211) is a hydraulic clamping unit designed for high precision and reliability in securing components on roller rail systems. This robust clamping element can be utilized across all SNS roller guide rails, ensuring versatility for various applications. It boasts a compact design, which is fully compatible with DIN standards, making it suitable for integration into numerous setups without the need for extensive modifications. The KWH 4505 BS1A is engineered with a solid, rigid steel housing that has been chemically nickel-plated to resist corrosion and wear. Its high positioning accuracy is ideal for tasks requiring meticulous alignment, while the integrated all-around sealing prevents contamination and ensures long-term operation even in harsh environments. The unit features special pressure diaphragm technology which provides maximum functional reliability without pressure losses or leakage. With the ability to deliver over 1 million clamping cycles and a Bd value indicating its endurance, this clamping element is designed for both dynamic and static stabilization in the axial direction. It offers a continuously adjustable pressure range from 0 to 450 bar to accommodate varying operational demands. Additionally, the clamping element incorporates positivelocking, large-surface contact profiles that contribute to its maximum axial rigidity. For ease of installation and maintenance, the KWH 4505 BS1A includes threaded connections on both sides for hydraulic linking. The permissible ambient temperature range for this device spans from -20°C to +80°C, allowing it to function effectively in diverse working conditions. The nominal size of the unit complements several profiled rail systems including sizes A, B, E, H, N and S. In summary, Bosch Rexroth's hydraulic clamping unit KWH 4505 BS1A (R181044211) provides a reliable and precise solution for securing components on roller guide rails with its durable construction, adjustable pressure settings and compatibility with multiple rail sizes. Its specialized design ensures longevity and optimal performance in various industrial applications.
