ROLLER GUIDE RAIL CARBON STEEL RSA-025-SNS-S-MA-BS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth R.GUIDE RAIL CS (R180523131) is a high-precision roller guide rail designed to deliver superior performance in linear motion applications. This product stands out with its SNS size format, which denotes a slimline width, normal length, and standard height, making it suitable for various installation spaces. The guide rail itself is crafted from robust carbon steel (CS) to ensure durability and longevity. Equipped with an MA fastener, the R.GUIDE RAIL CS allows for easy bolting from above, streamlining the installation process. The BS cover includes a corrosion-resistant cover strip made from spring steel compliant with DIN EN standards and aluminum strip clamps that facilitate simple and secure mounting without needing threaded holes on the end faces. The guide rail's accuracy class is defined as super precision, highlighting its capability to support applications requiring extremely high levels of precision. It comes as a one-piece section with hardened raceways that have been smoothed on all sides to reduce friction and wear. This design feature contributes to the guide rail's maximum rigidity in all load directions and an exceptionally high torque load capacity. Further specifications include a permissible ambient temperature range of -10°C to +80°C for standard operation. For applications involving temperatures outside this range, consultation with Bosch Rexroth is recommended. The maximum length for this model is Lmax = 2 meters, ensuring compatibility with various system sizes. The mass of the guide rail is 3.3 kg/meter, reflecting its sturdy build without excessive weight addition. With a pitch T of 60 mm for the profiled rail systems and an overall height H of 23 mm including the cover strip, this model provides substantial support while maintaining a compact form factor. Bosch Rexroth's R.GUIDE RAIL CS is part of their roller rail system product group ID and offers an optimal solution for those seeking a reliable linear guide according to DIN specifications that prioritize both precision and strength.
