BALL GUIDE RAIL CARBON STEEL KSA-025-BNS-H-MA-SK

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R167625332) is a high-precision ball guide rail designed for applications requiring maximum rigidity and torque load capacity in challenging environments. This guide rail is part of the BNS series, featuring a wide format with standard height and length. Constructed from carbon steel (CS), it offers exceptional durability against mechanical influences such as shocks, making it suitable for use in very harsh conditions. The guide rail comes in a two-piece format, allowing for double-row mounting from above using fastener type MA (bolting from above). While steel caps are necessary for the complete assembly of this guide rail, they are not included with the product and must be ordered separately. The high accuracy class of this product ensures precise movements and reliable performance under demanding circumstances. This model has been designed with no extra space required at the ends of the rail, enabling compact installation. The product's specifications include a permissible ambient temperature range from minimum to maximum degrees Celsius; however, consultation is advised for operation at negative temperatures. The B.GUIDE RAIL CS is characterized by its T profiled rail system, with a mass of kg/m and an option to calculate the recommended rail length using the provided formula. The pitch T of the guide rail accommodates various lengths up to a maximum specified length Lmax. As a component of Bosch Rexroth's linear guide systems, this ball rail system adheres to DIN standards for linear guides. It offers an optimal solution where robustness and precision are paramount, such as in automation equipment or heavy-duty machinery where linear motion is critical. Installation instructions are available upon request to ensure proper setup and utilization of the full capabilities of this ball guide rail system.
