BALL RUNNER BLOCK CARBON STEEL KWD-020-CNS-C1-H-1
Manufacturer: Bosch Rexroth
Material #: R16725132Y
Model : B.RUNNER BLOCK CS KWD-020-CNS-C1-H-1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-020-CNS-C1-H-1 (R16725132Y) is a high-precision ball runner block designed for linear motion applications requiring compact width, standard height, and normal length configurations. This runner block features a body made from unalloyed steel CS and is classified in preload class C, indicating a low preload, while belonging to accuracy class H for high precision. It comes equipped with a ball chain and initial lubrication using Roller bearing grease Dynalub, enhancing its smooth running capabilities.
With an overall length of . mm, the B.RUNNER BLOCK CS KWD-020-CNS-C1-H-1 is built for interchangeability, allowing it to be combined with guide rails of every accuracy level. It excels in environments where high torsional moments are present and lateral space is restricted. This model supports high load ratings equally in all four main loading directions and offers the possibility of long-term lubrication over several years.
The unit's dynamic characteristics are outstanding due to its optimized entry-zone geometry and the high number of balls which minimize elastic deflection variations. The design incorporates an integrated all-around seal and additional mounting screw holes at the center for improved rigidity under lift-off and side loading conditions. Moreover, it has end-face fastening threads for attachments, contributing to its versatility.
The B.RUNNER BLOCK CS KWD-020-CNS-C1-H-1 can handle very high torsional moment load capacity and features excellent resistance against torsion. Its ball chain ensures a low noise level and optimal travel behavior. The permissible ambient temperature range for this product is from min ... max °C, making it suitable for various operating environments.
This Bosch Rexroth runner block also boasts self-aligning capabilities to compensate for misalignments without the need for self-alignment mechanisms. It has been pre-lubricated at the factory to ensure immediate operation upon installation. With its robust construction from carbon steel and advanced sealing technology such as the DS double-lip seal option, this product promises durability and performance in demanding linear motion systems.
$357.79 USD
More are expected on February 24, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 24, 2025 when ordered in
