BALL RUNNER BLOCK CARBON STEEL KWD-025-BNS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-BNS-C1-N-1 (R16712142Y) is a state-of-the-art linear motion rolling guide designed for precision and durability. This ball runner block is part of the Ball Rail Systems and features the BNS size format, which specifies its width as wide, length as normal, and height as standard. The runner block body is constructed from unalloyed steel CS, ensuring robustness and longevity. Equipped with a low preload (Preload class C) and standard accuracy class N, the runner block offers reliable performance with minimal friction. It includes a ball chain that contributes to its smooth operation and low noise emission during motion. The product comes with initial lubrication and preservation for immediate use upon installation. This runner block has an overall length of . mm and boasts excellent dynamic characteristics that support high torsional moments on rails, maintaining high load ratings in all four main loading directions. Its design allows for long-term lubrication over several years, enhancing its maintenance-free operation. For versatile mounting options, attachments can be mounted from both above and below the runner block. The integrated all-around sealing system ensures protection against contaminants, contributing to the unit's extended service life. Additionally, it features two extra mounting screw holes at the center for improved rigidity under various loading conditions. The B.RUNNER BLOCK CS KWD-025-BNS-C1-N-1 is compatible with all BNS ball guide rails and offers a wide range of accessories to cater to different application needs. It also includes end-face fastening threads for attachments and a straight lube connection loosely attached for easy maintenance. Designed to handle very high torsional moment load capacities with excellent torsion resistance, this ball runner block is prelubricated at the factory which along with its ball chain design ensures quiet operation with optimal travel behavior. It's suitable for applications that require precise linear guidance under high load conditions while maintaining smooth movement.
