BALL RUNNER BLOCK CARBON STEEL KWD-025-SKS-C0-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-SKS-C0-H-1 (R166629322) is a high-precision ball runner block designed for linear motion applications requiring compactness, accuracy, and reliability. This runner block features a slimline width, short length, and standard height format (SKS), making it suitable for situations where space is limited in both longitudinal and transverse directions. Constructed from unalloyed steel CS, it boasts a preload class C indicating it is preload-free and an accuracy class H for high precision. The product comes equipped with a ball chain that ensures low noise levels and smooth travel behavior. Its optimized entry-zone geometry and the high number of balls reduce the variation in elastic deflection across the system. The B.RUNNER BLOCK CS KWD-025-SKS-C0-H-1 has integrated all-around sealing to protect against contaminants while also featuring a minimum quantity lubrication system with an oil reservoir, extending maintenance intervals. This runner block can be used on all SNS/SNO Ball Guide Rails by Bosch Rexroth, providing excellent dynamic characteristics due to its design. It also offers versatility with end-face fastening threads for various attachments. The runner block is pre-lubricated at the factory for immediate use upon installation. Additionally, this model allows attachments to be mounted from above and sustains high load ratings in all four main loading directions. With limitless interchangeability within each accuracy class of ball guide rail systems, it provides flexibility for different application requirements. The product's overall length is . mm, with a nominal size . It can operate within an ambient temperature range of min ... max °C for short periods (consultation required for negative temperatures). The static load rating C0 and dynamic torsional moment load capacity Mt are determined according to DIN ISO standards over a 100 km travel distance; however, these values can be multiplied by 1.26 if only 50 km are stipulated in comparison. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-025-SKS-C0-H-1 (R166629322) offers exceptional precision and durability for various linear motion applications where space constraints exist without compromising on performance or maintenance requirements.
