BALL RUNNER BLOCK CARBON STEEL KWD-015-SKS-C1-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SKS-C1-H-1 (R166611320) is a high-precision ball runner block designed for linear motion applications requiring compactness and accuracy. This model is part of the SKS series, which features a slimline width, short length, and standard height. The runner block body is constructed from unalloyed steel CS and is preloaded to class C for low preload while maintaining a high accuracy class H. It does not include a ball chain but comes with initial lubrication and preservation. The B.RUNNER BLOCK CS KWD-015-SKS-C1-H-1 has an optimized entry-zone geometry that, together with a high number of balls, minimizes variations in elastic deflection across its operational range. It offers excellent dynamic characteristics suitable for various applications where space is limited in both longitudinal and transverse directions. The product's design allows for attachments to be mounted from above and provides the same high load ratings in all four main loading directions. This model boasts integrated all-around sealing to protect against contaminants and employs a minimum quantity lubrication system with an integrated reservoir for oil lubrication, ensuring long-term maintenance-free operation. The presence of an end-face fastening thread enables secure attachment of components. Compatible with all SN/SNO ball guide rails, this ball runner block ensures limitless interchangeability within each accuracy class, facilitating versatile use across different systems. Its friction coefficient ranges between 0.01 to 0.02 without seal friction considered, enabling smooth motion under various conditions. Additional features include self-alignment capabilities to compensate for misalignments without the need for a ball chain standard. The product's static load rating C0 and dynamic torsional moment load capacity Mt are determined based on travel as per DIN ISO norms. Designed with industry-standard specifications in mind, the Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SKS-C1-H-1 (R166611320) represents a reliable choice for engineers looking to optimize their linear motion systems while ensuring accuracy and longevity.
