BALL RUNNER BLOCK CARBON STEEL KWC-025-FKN-C0-N-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-025-FKN-C0-N-2 (R166329410) is a high-precision ball runner block designed for applications where space is limited in the upward and longitudinal directions. It features a size format FKN with a flange width, short length, and low height, crafted from unalloyed steel CS. This runner block boasts an accuracy class N (standard) and is preload class C (preload-free), ensuring smooth motion without initial tension. It does not include a ball chain and comes preserved but without initial lubrication. With its angular lube nipples loosely attached, the B.RUNNER BLOCK CS offers easy maintenance and long-term lubrication possibilities over several years. The product’s end-face fastening thread accommodates all attachments, while it can be used on all SN/SNO ball guide rails due to its versatile design. The runner block features integrated all-around sealing, contributing to its robustness against environmental contaminants. This model has been engineered with an optimized entry zone geometry and a high number of balls which significantly reduces frictional oscillations and minimizes variations in elastic deflection under load, enhancing travel accuracy up to six times compared to standard systems. The dynamic load capacity C and the static load rating are determined based on DIN ISO standards, ensuring reliable performance. The B.RUNNER BLOCK CS also comes with optional features such as an integrated, inductive, wear-free measuring system for precise operation monitoring. Its self-aligning capability allows for compensation of misalignments without additional components. Moreover, the product's design enables easy interchangeability with guide rails across various accuracies. With permissible ambient temperature ranges from minimum to maximum degrees Celsius for short durations and specific requirements for operation at negative temperatures, this runner block caters to a broad spectrum of environmental conditions. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWC-025-FKN-C0-N-2 (R166329410) is an adaptable linear guide solution that offers maximum precision in restricted spaces while maintaining low friction levels and providing long-lasting performance with minimal maintenance needs.
