R166221320

BALL RUNNER BLOCK SUPER CARBON STEEL KWD-025-SKS-C1-H-1

Manufacturer: Bosch Rexroth

Material #: R166221320

Model : B.RUNNER BLOCK SS KWD-025-SKS-C1-H-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK SS KWD-025-SKS-C1-H-1 (R166221320) is a high-precision ball runner block designed for linear motion applications requiring self-alignment and high load capacity. This runner block is a key component in Bosch Rexroth's Ball Rail Systems, which are renowned for their reliability and performance. The model features a size 25 slimline SKS format with a short length and standard height, constructed from durable carbon steel (CS). It offers low preload (class C) and high accuracy (class H), ensuring precise movement without the need for a ball chain. The self-adjusting capability of this runner block allows it to compensate for alignment errors, ensuring smooth operation and an extended service life. The overall length of the runner block is meticulously designed to maintain compatibility with all SNS Ball Guide Rails, providing limitless interchangeability within each accuracy class. This versatility makes it ideal for applications that require compensation for large tolerances in adjoining structures. Equipped with initial lubrication and preservation, the B.RUNNER BLOCK SS KWD-025-SKS-C1-H-1 operates smoothly due to its optimal return system and ball pickup design. It boasts the same high load ratings in all four main loading directions, which is facilitated by lube fittings with metal threads on all sides. The product's design enables greater parallelism and height offsets of mounting bases, enhancing its application scope. This runner block can be utilized in various industrial settings where low noise levels, excellent dynamic characteristics, and the ability to handle significant dynamic loads are essential. Its compact design does not only provide self-alignment up to specific deviations but also ensures that it can withstand maximum permissible torsional moments while maintaining smooth operation across a wide range of ambient temperatures.

$174.44 USD

Availability:  83  In Stock
  Add to Cart
Available for immediate shipment

Qty: Delivered as early as November 26, 2024 when ordered in
